Solar direct drive blood bank

VC200SDD-B

Bringing Dulas’s latest SDD innovation in cold chain refrigeration to the blood chain, the VC200SDD-B is a bespoke design suitable for storing blood products and comes with 6 dedicated blood baskets for easy stock management.

The high energy density of the PCM lining means rapid cooling, and the ability to run in cloudy, low light conditions means greater reliability than other battery-free solutions.

The VC200SDD-B features integrated WHO PQS-accredited Equipment Monitoring System (EMS) technology with audible and visual alarm functions that can be activated if temperatures exceed 6 °C. With Level 3 remote monitoring and real-time alerts, our system ends the silence of unmonitored equipment, ensuring your contents remain protected.

This product includes a 3 year subscription to the BeyondColdCloud™ portal which enables you to monitor your cold chain in one easy to use platform. With proactive alerts, you can be safe in the knowledge that you will be notified of any temperature deviations.

Learn more about our Connected range

Features and benefits

Manufactured in our factory in the UK, Dulas products are renowned for their performance, quality and safety

With long lasting autonomy you can rely on Dulas products to keep your vaccines safe

Dulas solar refrigerators are battery-free and use an advanced non-corrosive phase change material (PCM) which thaws at exactly +5°C

Dedicated blood baskets for easy stock management and optimum airflow

Dulas products have Grade A User-independent Freeze Protection (UIFP)

All Dulas refrigerators have integrated remote temperature monitoring as standard

climate friendly and CFC-free

for easy handling

Dulas Refrigerators will operate at a stable +2°C to +8°C in an extended ambient operating range of +5°C to +43°C

Renowned for their quality and reliability, the Dulas range of refrigerators are built to perform effectively in challenging environments over long periods of time

to keep vaccines safe

power system for easy installation

Technical specification

download full specs
Model VC200SDD-B
Performance
Net blood bag storage capacity 120 x 280ml bags
Gross volume 205 litre
Climate zone Hot zone (+43 °C)
Minimum rated ambient temperature +5 °C
Autonomy time † 79 h 29 min at +43 °C
Solar array size > 900 Wp
Refrigerator Dimensions
External dimensions: H x W x D 980 mm x 1280 mm x 750 mm
Shipping dimensions: H x W x D 1180 mm x 1355 mm x 825 mm
Net weight 153 kg
Shipping weight 199 kg
System Dimensions
Shipping dimensions: H x W x D 350 mm x 1810 mm x 1220 mm
Net weight 64 kg
Shipping weight 104 kg
Technical Details
Operating voltage 24 to 45 Vdc
Minimum starting voltage 24 Vdc
Minimum starting power 50 W
Minimum solar radiation for continuous running 200 W/m2 (using 900 Wp array)
Compressor Secop (Danfoss)
Refrigerant R600a

†Autonomy is the amount of time that the refrigerator can maintain the vaccine load within the temperature range of +2 °C to +8 °C with minimal solar radiation available and at the maximum rated ambient temperature.
